PRODUCT DESCRIPTION

Semi-Automatic Thick-Gauge Thermoforming Machine

A semi-automatic thick-gauge thermoforming machine is an industrial system designed to form heavy-gauge plastic sheets (typically 3mm to 12mm+ thick) into large, three-dimensional parts with a blend of automated processes and crucial operator intervention.

SPECIFICATIONS

Model	Max forming area(mm)	Max Forming height(mm)
ZS-1209	1200x900	700
ZS-1209	1200x900	700
ZS-1212	1200x900	700
ZS-1512	1500x1200	700
ZS-1515	1500x1200	700
ZS-1812	1800x1200	700
ZS-1815	1800x1200	700
ZS-2012	2000x1200	700
ZS-2015	2000x1500	1000
ZS-2015	2500x1500	1000
ZS-2518	2500x1500	1000
ZS-2520	2500x1500	1000
ZS-3015	3000x1500	1000
ZS-3020	3000x2000	1000
ZS-3025	3000x2500	1000
ZS-4025	4000x2500	1000

PRODUCT FEATURES

Product Features of Semi-Automatic Thick-Gauge Thermoforming Machines

Optimal Balance of Automation and Manual Control

The machine automates the critical, repetitive, and heat-intensive phases of the cycle (heating, forming, cooling) to ensure consistent quality. Meanwhile, manual intervention is used for loading/unloading and mold changes.

High Cost-Effectiveness and Lower Investment

Capital Investment: Offers a much more affordable entry point compared to fully automated thermoforming lines.
Mold Flexibility: Compatible with cost-effective mold materials (e.g., structural foam, wood, epoxy) which is ideal for prototyping and short-to- medium production runs.
ROI: Provides the best return on investment for manufacturers who do not require high-volume, 24/7 unattended production.

Superior Flexibility for Varied Production

Quick Changeovers: The manual loading/unloading and mold setup allow for rapid switching between different jobs and product designs.
Ideal Application: Perfect for custom part manufacturing, prototyping, and producing large parts where full automation is not economically justified (e.g., vehicle interiors, equipment housings, medical cart panels).
